Weatherproof Rf Lc Filter / Lc Bandpass Filter High Aseismatic Capability

Reject Passive Components Weatherproof N Female High Pass Cavity LC RF Filter

Quick Details

Place of Origin:Sichuan, China
Brand Name:sinoscite, Sinoscite
Model Number:BPF4-6GS-0563
Type:LC Filter
Transfer Function:Band Pass
Nominal Center Frequency:12.7-13.3GHz
Insertion Loss:1dB, <0..8dB
Input Impedance:50Ohm
Stopband Attenuation:20dB
Description:low pass filter rf filter
Impedance:50Ohm
Filter Type:Low Pass
Mounting Type:Surface Mount
Height (Max):200
Number of Lines:2
Impedance @ Frequency:50Ohm
Voltage Rating - DC:220v
Voltage Rating - AC:220V

Our Products Features:

1. Good temperature behavior, High aseismatic capability.

2. Low Insertion Loss, High power handling.

3. High quality, Low price, Fast delivery.

4. Custom design available upon request.

5. Meet ROHS standard.

6. Guaranteed for one year standard

Typial Applications

Single-phase power supplies,swich-mode power supplies.

Small to medium-sized machines household equipment.

Test and measurement equipment.

Medium equipment.

1~ 2000MHz High Pass LC RF Filter

Pass Frequency (MHz)	3dBCut-off Frequency (MHz)	Transition Frequency Bandwidth(MHz)	Out of band inhibition(dB)	Insertion Loss (dB)	Intra Band Fluctuation (dB)	Internal reflection loss(dB)
>180	180	<20	>50	<1.5	<1.5	>10
>240	240	<26	>50	<1.5	<1.5	>10
>370	370	<240	>50	<1.5	<1.5	>10
>650	650	<70	>50	<1.5	<1.5	>10
>900	900	<100	>50	<1.5	<1.5	>10
>1500	1500	<160	>50	<1.5	<1.5	>10
>2000	2000	<220	>50	<1.5	<1.5	>10

Forms are specify frequency range and other ranges available

Tip: Attention should be paid to the good grounding of the enclosure when it is used, otherwise it will affect the external suppression and flatness index

Packaging & Shipping

Packing:Standard exporting carton.

each product individually wrapped, high density foam protection professional packing protect product safely.

Airport: Shanghai airport, Shenzhen airport and Chengdu Airport.
